Switching Power Supply 100-240V AC to 24V DC, 5A/10A/12.5A/15A/20A/40A Available

Be the first to review this product

Availability: In stock

Regular Price: $25.00

Special Price $21.70

Quick Overview

This 24V power supply has reliability written all over it. This power supply will power up to 40 amps, and has an output of 960 Watt.

* Required Fields

Regular Price: $25.00

Special Price $21.70

Switching Power Supply 100-240V AC to 24V DC, 5A/10A/12.5A/15A/20A/40A Available

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

Details

With a PWM switching design, composed by a professional integrate circuit, this 24V power supply has reliability written all over it. Meant for heavy duty or industrial / architectural purposes, this power supply will power up to 40 amps, and has an output of 960W.

Ultra efficient design with built in stabilizer ensures optimal power delivery for your lighting project.

DC Voltage: 24V
Voltage Tolerance: ±1%
Rated Power: 5Amp/120W, 10Amp/240W, 12.5Amp/300W, 15Amp/360W, 20Amp/480W, 40Amp/960W
Input Voltage Range: 100-240V AC to 5V DC
AC Current: 3.2A/115 V 1.6A/ 230 V
Efficiency: 82%
Leakage Current:<3.5mA/240VAC

Over Voltage Protection: 115%~135%
Working Temperature & Humidity: -25℃~+45℃; 20%~90 %RH
Vibration: 10~500Hz, 2G 10min./1cycle, period for 60min, each along X.Y.Z axes
Withstand Voltage: I/P-O/P: 3KVACI/P-FG: 1.5KVACO/P-FG: 0.5KVAC
Isolation Resistance: I/P-O/P, I/P-FG, O/P-FG: 500VDC/100MΩ
Safety Standards: Design refer to UL1012, EN60950
EMC Standard: Design refer to EN55022, EN55024, EN61000, IEC1000-4-2, 3, 4, IEC1000-3-2
