LED RGB Amplifier, 12VDC, 4A/Ch
This LED amplifier is a constant voltage power repeater and works with 12V DC. It is suitable for all of our RGB controllers to expand power output.
Input: Screw terminals for easy connection to stripped power supply wires and a male barrel plug for easy connection to out power supplies.
Output: Screw terminals for easy connection to our RGB Flexible LED Strips or control cable.
You can connect and control up to 4A/Ch of output (4x rolls of 30/m RGB Flex Strip).
Supports PWM (Pulse-Width-Modulation) control for 0-100% Dimming and Full Color Control.
You can stack amplifiers (2x repeaters connected = 8A/Ch) (4x repeaters connected = 16A/Ch)
Simply connect the output of one of our RGB Controllers (DMX, IR, or RF) to the input of this controller. Then, connect a power supply to the (+) and (-) and connect your RGB LED Strips to the Output.
Check the detailed manual of this LED RGB Amplifier
Applications:
The RGB amplifier applies to the voltage-controlled LED controller; it can receive PWM (Pulse Width Modulation). Each time add one RGB amplifier, the connecting number of LEDs will be more than twice.
Receive RGB signal from LED controller and send the signal to another group of LED source
Extend 10 meters of SMD5050 30LEDs/m RGB LED Strips/ 5 meters of SMD5050 60LEDs/m RGB LED Strips
