DX8 RGBW Wireless Touch Screen Wall Controller, 100-240V AC
Glass screen
Compact 86mm x 86mm wall mount
Simple to install
100 - 240V input
30m receiver range
Output Signal: 2.4G +DMX512
4 Zone Control Mode
Set up of the RGBW Wireless Touch Screen Controller is very simple and so is installation. For additional wireless light zones - use R4-5A Wireless Zone Interface
Download user manual.
Input voltage: AC100~240V
Output signal: RF 2.4G+DMX512
Control mode: 4 Zones control
RF Remote distance: 30m
Working temperature: -20℃~60℃
Dimensions: L86×W86×H36mm
This DX8 wireless multi-zone RGBW controller is a sleek and professional wall mounted controller for 4-channel RGBW colour LED lighting, provides you with 4 zones and mode function with 11 different modes, brightness control by zone, speed adjustment and separate brightness control per colour. It features a high-grade tempered touch sensitive glass front panel, an effect mode selector, brightness/speed control, a touch colour wheel, and a 4 zone switch selection.
It is 100-240V mains powered at the wall, and suitable for 12/24V DC lighting circuits via a wireless receiver. It fits perfectly into standard back-boxes and does not require any custom accessories.
This wall mounted controller is capable of controlling RGBW LED lighting remotely in 4 separate zones via 2.4Hz wireless RF within a 30 metre range. Alternatively the unit has a DMX 512 output on the rear for controlling DMX lighting circuits directly via a wired connection.
The DX8 features a quiet musical chord and LED indicator light on each touch, giving you visual and auditory feedback. It also incorporates the latest T-PWM dimming technology which gives a perfectly smooth dimming performance. This high accuracy system gives a much more precise and pleasant touch control than most alternative products available.
Note: wireless receivers sold separately.
