16 Channel DMX RDM to PWM Decoder, 3A/CH, XLR-5, RJ45, 12-24V DC

16 Channel DMX RDM to PWM Decoder, 3A/CH, XLR-5, RJ45, 12-24V DC

SKU
BLB10368

16 Channel DMX RDM to PWM Decoder, 3A/CH, XLR-5, RJ45, 12-24V DC

Special Price $139.50 Regular Price $155.00
In stock
SKU
BLB10368
  • Buy 5 for $129.50 each and save 7%
  • Buy 10 for $125.50 each and save 10%
  • Buy 30 for $119.50 each and save 14%
Overview

16 channels output, and Max. 3A current per channel, up to 1152W output power
3 button interface with OLED display for intuitive configuration
4 optional modes: single colour, colour temperature, RGB and RGBW
Supports 3 kinds of DMX ports with signal isolation function: 5-pinXLR, RJ45 and green terminal (with signal amplifier function)
Operations can be completed via the RDM master console, such as parameters browsing & setting, DMX address setting, equipment recognition, etc.
16 bit (65536 levels) / 8 bit (256 levels) with grey level optional

Download User Manual

DMX decoder for low voltage circuits. With 16 output channels, this unit is ideal for controlling larger circuits of RGBW, RGB, CT, or single colour LED Strip. Fitted with OLED screen and touch buttons for easy setup.

This decoder also has the option to assign multiple channels to one address. Dimming curve options include; standard, linear, LOG, custom 0.1-9.9 dimming curve.

The decoder requires a low voltage input. It receives a DMX control signal from a suitable controller in order to supply the correct dimming output across 16 channels. DMX connects via standard XLR-5, RJ45 plugs or screw terminals. The low voltage supply and lights connect via screw terminals on the side of the unit. A DMX signal amplifier is also built in to the unit.

The decoder operates on a low voltage 12~24V DC circuit, providing a PWM output, ideal for dimming LEDs.

Specification

Input signalDMX512/RDM
Voltage12V~24V DC
OutputConstant Voltage
Channels16
Current3A ×16CH Max 48A
Max output power576W/1152W(12V/24V)
Dimensions (mm)180L 122W 39H
